Model Control Commands
Table F-2 Field Outlining Settings
The printer application should use Field Outline commands to
determine how to print field outlining on the characters that follow it.
The following points should be noted:
• Field outline begins with the character directly after the MCC Field
Outline command and ends with the character directly after the
next MCC Field Outline command. Character data includes the
space character and blank space of the MCC Horizontal
Tab skip.
• Field outline should be printed for transparent data specified by the
MCC Transparent Mode.
Decimal Binary Action
0 0000 0000 Reset/No Field Outline
1 0000 0001 Draw bottom line only
2 0000 0010 Draw right vertical line only
3 0000 0011 Draw bottom and right vertical lines
4 0000 0100 Draw top line only
5 0000 0101 Draw top and bottom lines
6 0000 0110 Draw top and right vertical lines
7 0000 0111 Draw top, bottom, and right vertical lines
8 0000 1000 Draw left vertical line only
9 0000 1001 Draw left vertical and bottom lines
10 0000 1010 Draw left and right vertical lines
11 0000 1011 Draw left, right, and bottom lines
12 0000 1100 Draw left vertical and top lines
13 0000 1101 Draw left, top, and bottom lines
14 0000 1110 Draw left, top, and right lines
15 0000 1111 Draw box
