332 Appendix F
Printer Filter Application for Double-Byte Character Sets
Model Control Commands
Characters per line. Valid numbers are:
1–158
For 6 double-byte or 12 single-byte characters per inch
1–132
For 5 double-byte or 10 single-byte characters per inch
LPP
Lines per page (the number of lines per logical page).
Valid numbers are 1–127.
LPI
Lines per inch. Supported numbers are 4 and 6 LPI.
SDS
Single or double space per line selection. Valid numbers
are:
0
Single spacing
1–255
Double spacing
CPI
Characters per inch. Valid numbers are:
5 or 6
For double-byte characters
10 or 12
For single-byte characters
lang
To help determine field outlining coordinates, it is
necessary to know the size of the font. This byte
represents the host language that was selected for the
TN3270 emulation program as shown in the table
“Host Language Selected for SPOF.”
Table F-1 Host Language Selected for SPOF
Num Country
0 United States
1 United Kingdom
2 Germany
