330 Appendix F
Printer Filter Application for Double-Byte Character Sets
SPOF Format
SPOF Format
The SPOF output from the TN3270 emulation program contains a
number of model control commands (MCCs) which control the format of
the output. When invoked, the filter application decodes the MCCs found
in the SPOF and translates them to the appropriate printer function.
It may also be necessary to modify the printer Model File (for example, to
download the correct fonts for a particular language).
