Appendix C 309
File Transfer Messages
Host File Transfer Messages
The file transfer process cannot take place because the maximum
number of open files (either the overall limit for the HP-UX computer or
the limit for an individual process) has already been reached. Close any
unnecessary files used by other processes, or wait for any other file
transfers currently in progress to complete. Then retry the command.
TRANS117
The specified local file is already in use. File
transfer was canceled.
The file specified has already been opened by another process that
prevents you from accessing it. Stop the other process and retry the
command. (This message might also be displayed if the file name you
specified was the name of a directory.)
TRANS118
The local disk or diskette is write protected. File
transfer was canceled.
Check that you are accessing the correct disk or diskette, or remove the
write-protect tab from the diskette. Then retry the operation.
TRANS119
The local diskette drive is not ready. File transfer
was canceled.
Check that you are accessing the correct diskette drive or that the
diskette is inserted properly and the drive door is closed. Then retry the
operation.
TRANS124
Message below was received from the host: messagetext
Consult your host personnel for information about the host message
shown.
TRANS999
The 3270 emulation program has not been loaded. File
transfer was canceled.
You tried to use a file transfer command when the TN3270 emulation
program was not running. Start the TN3270 emulation program and
retry the command.
