292 Appendix B
Status Line Information
Program Check Codes
752 Out of range address for SEA, RA, or EUA order
MF order addressed nonfield attribute location
753 Data stream data after Rd, Rd Mod, EAU command
Invalid parameter following SFE, MF, SA, GE, or RA order
754 Data stream terminated before end of order
755 Invalid command for data stream
756 Error in a structured field
758 Incorrect Set Reply Mode command
759 Incorrect Set Reply Mode attribute type indicator
Read Partition was not the last structured field
Incorrect structured field length indicator
Structured field not complete
Incorrect Read Partition type indicator
760 Invalid Set Reply Mode attribute byte
761 Incorrect partition indicated
771 Invalid command within a structured field
778 ACTLU type not COLD or error recovery procedure (ERP) —internal
error
779 Violation of pacing rules
780 Error in a graphic program (graphic data, picture, SF command, and so
on)
781 GDM check—mistake in a graphic SF command
782 GPP check—graphic command error
Number Description
