Appendix B 291
Status Line Information
Program Check Codes
471 Extended data stream function not supported
472 Read state error
474 The device does not support extended data stream
475 WCC had "Start Print" but not last structured field
498 Negative response received
499 An internal error occurred; see the error log file for details
701 Unsupported category
702 Received RU was too large
703 Unsupported function
704 Unrecognized format indicator
705 Sequence number error
706 Chaining error
707 Bracketing error
708 Data received when in data traffic set state
709 Data received when not in receive state
711 Session constraints exceeded
712 Bracket bid refused—no ready to receive (RTR)
713 Session was already set up
726 Negative acknowledgement received
727 Exception request received
728 Change direction (CD) required
729 Read Partition Query structured field sent in incorrect state
747 SCS data stream error
750 Invalid command received
Number Description
