286 Appendix B
Status Line Information
Record/Replay ID
Record/Replay ID
The Record/Replay ID messages remind you of the PF key identifier for a
keystroke sequence you are recording or replaying.
RECORD nn
Indicates that you are recording a keystroke sequence
identified by the PF key numbered nn.
RECORD PF KEY (list of PF keys)
Indicates that you pressed the RECORD key to start
recording a keystroke sequence and shows the PF keys
that already have sequences assigned to them. Press a
PF key to identify the sequence.
REPLAY nn
Indicates that you are replaying a keystroke sequence
identified by the PF key numbered nn.
REPLAY PF KEY (list of PF keys)
Indicates that you pressed the REPLAY key to start
replaying a keystroke sequence and shows the PF keys
that already have sequences assigned to them. Press
one of the PF keys shown to identify the sequence to
replay.
BUFFER LOW (mm)
Indicates that you have already entered 1475
keystrokes or more while recording a keystroke
sequence (the maximum number of keystrokes in any
one recorded sequence is 1500). The value mm is the
number of further keystrokes you can record before
reaching the limit (up to 25).
