Appendix A 263
Default Keyboard Mappings
Alphabetical List of Functions and Corresponding Keys
Alphabetical List of Functions and
Corresponding Keys
The following table lists all 3270 functions (other than character keys) in
alphabetical order, and matches these functions to the default keys and
key combinations assigned to them.
Table A-8 All 3270 Function Keys
Function
Default
Mapping
Current
Mapping
Key Group
ACTIONS Ctrl + U Miscellaneous system
ALT CURS Esc A 3270 system
ATTN Ctrl + A Program access
BACKSPACE Ctrl + H Edit keys
BACKTAB Backtab Edit keys
CENT ¢ [ Character keys
CLEAR Ctrl + C Program access
CURS SEL Esc C Program access
DELETE Delete Edit keys
DEV CNCL Esc D Printer control
DOWN Down Edit keys
DUP Ctrl + D Edit keys
ENTER Enter or Ctrl +
M
Program access
ERASE EOF Ctrl + E Edit keys
ERASE INP Esc E Edit keys
EXIT Ctrl + X Miscellaneous system
