HP-UX TN3270 Users Guide, March 1998

Chapter 6 197
Customizing 3270 Emulation
Customizing Display Colors
This list box lists all the background colors you can
display on your terminal. The color highlighted in this
box is the color currently designated to represent the
background for the combination of host highlight
attribute and host feature currently selected.
Foreground
This list box lists all the foreground colors you can
display on your terminal. (If you are using a
monochrome display, the colors listed here depend on
the background color selected; for example, if you have
selected white background, only black is listed,
because this is the only valid foreground color.) The
color highlighted in this box is the color currently
designated to represent the foreground for the
combination of host highlight attribute and host
feature selected.
The following push buttons are available on the Choose Colors for
SESSnn dialog box:
<Default>
Choose <Default> to specify the TN3270 emulation
program's original color mapping for this session. For
more information, see “Using Default Color Mapping”.
<Copy>
Choose <Copy> to use the color mapping from another
session to define the color assignments in this session.
For more information, see “Copying Colors from
Another Session”. This push button is not selectable if
you have only one display session.
<OK>
Choose <OK> to confirm your choices.
<Cancel>
Choose <Cancel> to abandon any changes you have
made to the color mappings and retain existing
settings.
To customize how your terminal uses color and highlighting
characteristics to represent each combination of host feature and host
highlight attribute, follow these steps:
Step 1. Display the dialog box shown in Figure 6-12, “Choose Colors Dialog Box.”
Step 2. Choose a host highlight attribute.
