HP-UX 11i Version 1.5 Release Notes, May 2001

Table Of Contents
Workstation/Server Specific Information
Function Key Mappings
Chapter 2 33
Function Key Mappings
Between the time the system powers up and the EFI shell comes up or
the kernel is loaded, Alt-key combinations are created by sending the
combination ^[} followed by the key. The following key sequence
definitions apply:
Table 2-3 Non-Ascii Key Mappings
Key Normal Shift Ctrl Alt
ESC ^[
NS
a
NS NS
F1 ^[OP NS NS NS
F2 ^[OQ NS NS NS
F3 ^[OR NS NS NS
F4 ^[OS NS NS NS
F5 ^[OT NS NS NS
F6 ^[OU NS NS NS
F7 ^[OV NS NS NS
F8 ^[OW NS NS NS
F9 ^[OX NS NS NS
F10 ^[OY NS NS NS
F11 ^[OZ NS NS NS
F12 ^[O1 NS NS NS
Print Screen NS NS NS NS
Scroll Lock NS NS NS NS
Pause NS NS NS NS
Insert ^[[L NS NS NS
Delete
(7Fh)
b
NS NS NS
