compartment names. If you change the name of a compartment, you must reconfigure
any applications configured in that compartment as well.
NOTE: If you rename a compartment, you have essentially created a new compartment
and removed the compartment with the old name. You must change all references to
see the new compartment. The old compartment continues to exist on the system until
a reboot.
6.5.3 Running an Application in a Compartment
You can configure an application to run in a particular compartment by using one of
the following options:
• The setfilexsec command to configure the compartment attribute of a binary
file. For example, to configure the application apple into the compartment fruit,
enter the following command:
# setfilexsec -c fruit apple
• HP-UX RBAC,see Section 8.5.5.
6.5.4 Login Directly to a Compartment
The compartment login configuration enables users and administrators to login directly
to a compartment. It provides a mechanism to set controls on those users that are
allowed to login to a service running in a specified compartment or prevent access to
the system based on previously configured authorization information. For more
information, see HP-UX Compartment Login using Secure Shell (SSH):
www.hp.com/go/hpux-security-docs
Click HP-UX 11i Security Containment Software.
6.6 Troubleshooting Compartments
If something is not working on the system and you suspect the problem is occurring
because of the compartment structure, you can check the compartment rules as follows.
Problem 1: Access is not being controlled according to the compartment rules I
configured. Solution: the rules may not be set in the kernel. To check whether the
rules are set in the kernel, follow these steps:
1. Use the following command to list the valid compartment rules in the kernel.
# getrules
2. Use the following command to list all rules configured on the system, including
rules that have not been loaded into the kernel.
# setrules -p
3. Compare the output of the two commands. If they are the same, all rules are loaded
into the kernel. If the output differs, you need to load rules into the kernel.
6.6 Troubleshooting Compartments 123
