HP-UX IPQoS Configuration Files
Filter Blocks
Chapter 4 69
dscplo[w] n
Low end of DSCP field range. Valid range is 0 to 63 inclusive.
dscphi[gh] n
High end of DSCP field range. Valid range is 0 to 63 inclusive.
Specifying both dscplo and dscphi creates a filter that only matches traffic
with DSCP fields within that range. To select all non-default DSCP traffic,
specify dscplo 1 and dscphi 63.
dscp n
DSCP field value. Valid range is 0-63 inclusive.
This is equivalent to specifying the same value for dscplo and dscphi.
Specify this attribute when you want to specify a single DSCP value rather
than a range.
Do not specify this attribute with dscplo or dscphi.
dstphysaddr addr Physical (MAC) address. The addr string must contain only hexadecimal
characters, optionally separated in groups of two by a separator character.
The separator character can be either a colon (:) (the format used by ARP)
or a hyphen (-). The total number of hexadecimal digits in the string must
be less than or equal to 40.
Examples of legal addresses are as follows: 00:00:00:12:34:56,
00-00-00-12-34-56, or 000000123456.
An example of an illegal address is 00:00:00:12:34-56
This address is illegal, because the separator character must be consistent.
Priority Attribute
The priority attribute syntax is as follows:
Table 4-2 Supported Network Protocol Numbers
Network Protocol
Numbers
Protocol
0x800 IP over Ethernet
0x86DD IPv6 over Ethernet
