HP SIM 5.2

or greater

and HP Select Access

Table of Contents

Configuring HP SIM 5.2 and HP Select Access to use the same Windows users and user groups

..................

Summary

................................

.........

HP SIM

................................

...........

Configuration

................................

...............................

HP S

elect Access

................................

..............................

Configuration

................................

...............................

Creating new users and groups

................................

......

all to action

................................

......

Summary of content (5 pages)

PAGE 1
HP SIM 5.2 or greater and HP Select Access Table of Contents Configuring HP SIM 5.2 and HP Select Access to use the same Windows users and user groups .................. 2 Summary......................................................................................................................................... 2 HP SIM ........................................................................................................................................... 2 Configuration..............................
PAGE 2
Configuring HP SIM 5.2 and HP Select Access to use the same Windows users and user groups Summary HP Systems Insight Manager (HP SIM) 5.2 and HP Select Access can use the same Windows users and user groups for password-based authentication to HP SIM and other HP Select Access-protected resources. Access can then be managed by membership in or removal from the Windows user group. HP SIM Configuration In HP SIM, add the Windows user group.
PAGE 3
Configuration In HP Select Access, add a User Location for the same Windows domain used for HP SIM. Log in to the HP Select Access Policy Builder. From the menu, select ToolsUser Location Configuration to add a user location in the User location name field. Specify the Windows domain controller as the directory server. Port 389 is the standard port for LDAP, and port 636 is the standard port for LDAP using SSL that ensures the communication is encrypted over th e network.
PAGE 4
Note: To create and manage user passwords on the directory server (Microsoft Active Directory), SSL must be enabled for the user location. Figure 3: HP Select Access users tree To create a new user, right-click a user location in the User Tree, and select NewUser To create a new user group, select NewGroup. Right-click the group or user in the Users Tree and select Properties to add users to a group. Use the Group Membership tab to specify desired group memberships.
PAGE 5
Call to action To help us better understand and meet your needs for ISS technology information, ple ase send comments about this paper to: TechCom@HP.com. © 2009 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty.
