HP Tape Library Configuration Guide
Table Of Contents
- hp tape library configuration guide
- Configuration
- Configuring the Host System
- Windows NT
- Sun Solaris
- HP-UX Hosts
- Table 1 Drivers Needed
- Installing the Pass-Through Driver
- HSC or PCI Pass-Through Driver Installation
- 1. Run SAM.
- 2. Select Kernel Config, and press Return.
- 3. Select Drivers, and press Return.
- 4. Select sctl.
- 5. From the Menu Bar, select Actions. Select Add Drivers to Kernel, and press Return.
- 6. From the Menu Bar, select Actions. Select Create New Kernel, and press Return.
- 7. At the Are you sure prompt, respond Yes. Press Return.
- 8. After the status messages, select OK. Press Return. The system reboots.
- 1. Run SAM.
- Creating a Device File for the Robotics Controller
- Verifying the Installation
- Table 1 Drivers Needed
- MPE/iX Hosts
- Requirements
- Configuring the Host
- 1. Power on the library and host. Run ODE at the ISL prompt: ISL>ODE
- 2. Identify the device path through RUN MAPPER: ODE> RUN MAPPER ***STARTING EXECUTION OF MAPPER**...
- 3. Boot the system. At the MPE prompt, run sysgen and start the io section: sysgen SYSGEN version...
- 4. If not already configured, configure the differential card and the pseudo/target level of the ...
- 5. Configure the robotics controller and the drives (the pass-thru driver): io> adev 30 id=HPA466...
- 6. Verify the bindings between PATH, LDEV number, ID, PMGR (device drivers), and LMGR attributes ...
- a. Verify the binding for the device adapter (the fw/differential dam): io> lpath 10/4/4.0.0 PATH...
- b. Verify the binding for the targets (the transparent dm): io> lpath 10/4/4.0 PATH: 10/4/4.0 LDE...
- c. Verify the binding for the robotics controller (the pass-thru driver): io> lpath 10/4/4.0.0 PA...
- d. Verify the binding for the tape drives (the differential tape dm): io> lpath 10/4/4.1.0 PATH: ...
- e. To configure the Storage Node on the NetWorker server, verify the ldev specifications: io> Ide...
- a. Hold the configuration changes: io> hold
- b. Exit the io section: io> exit
- c. If you have followed the local convention for backing up the configuration file, keep the chan...
- d. Exit sysgen and reboot according to local convention: sysgen> exit
- 1. Power on the library and host. Run ODE at the ISL prompt: ISL>ODE
- Verifying the Connection
- Diagnostics
- Diagnostic support tools
- HP Library & Tape Tools
- Support Tools Manager (STM)
- STM is the primary HP-UX support tool. Though this document provides general information about ST...
- There are three user interfaces, all in /usr/sbin/stm/ui/bin/:
- There are three basic operations in STM:
- STM saves detailed information in several logs:
- Table 4 on page24 shows which types of STM tools are supported on the robotic and tape drive com...
- Table 4 Supported Tool Characteristics
- Table 5 Drive Expert Tool Command
- Table 6 Robotic Controller Expert Tool Command
- Firmware Update Tool
- When started, the firmware update tool will examine the firmware revision of the current SCSI dev...
- If no files are found (or no compatible files are found), it will display an error message statin...
- If you have enabled the licensed firmware update tool, you can start it by selecting [Utility], f...
- Sysdiag
- Sysdiag is the MPE/iX support tool, and provides a consistent user interface for support of tape ...
- Sysdiag is a licensed-use tool, so a user must first know and enter a diagnostics password. Enter...
- :suplicen
- Use of sysdiag also assumes knowledge of the ldevs at which the components to be supported are lo...
- :sysdiag
- This command will bring up the Diagnostic User Interface (DUI) prompt. Two diagnostics are availa...
- SCSITAC and SCSIDLT are divided into parts called “sections.” To use either of these diagnostics,...
- DUI> scsitac ldev=6 sc=4
- SCSITAC contains three sections:
- Sections 1 and 2 perform tests on the library, report results, and return to the DUI prompt. Sect...
- Table 7 SCSITAC Interactive Commands
- Table 8 SCSIDLT Interactive Commands
6 Configuring the Host System
HP-UX Hosts
To enable communication between the host and tape library,
appropriate drivers must be configured into the HP-UX kernel. Table
1 shows which drivers are necessary for each device.
NOTE Some drivers have different names, depending on whether or
not they are listed in the output of an ioscan or in the system
file.
Table 1 Drivers Needed
Device Driver Name
In ioscan In system file
SCSI Host Bus Adapter
(HSC or PCI Bus)
c720 c720
Fibre Channel Host Bus Adapter
fcp fcT1_fcp
fcT1 fcT1
fcT1_cntl fcT1_cntl
Fibre Channel Bridge or
Multiplexer
fcpmux fcpmux
Tape Library Robotics Controller
(HSC or PCI Bus)
sctl sctl
Tape Driver (HSC or PCI Bus) stape stape
