SAN Manager LM for HP-UX Release Notes
Table Of Contents
- 1 Installation
- 2 Storage Management
- 3 Troubleshooting
- Verifying that the Daemon is Running
- Viewing the LogFile
- An HP-UX Host is Grayed Out in the Administration Application
- No SAN Devices are Available on an HP-UX Host
- An Assigned Device Is Not Accessible to an HP-UX Host
- Error During Mounting: “Not A Block Device”
- An HP-UX Host is not Discovered by a SAN Manager LM Administration Host
- A Device Cannot be Unassigned from an HP-UX Host
- Index
8
System Requirements
System Requirements
All SAN Manager LM HP-UX hosts must meet the following system requirements:
•
HP-UX 11.0 64-bit
•
The following bundles from the DART 51 HP-UX software release must be installed:
Note
The Event Monitoring Service bundle is not required, but if it is present on the
host, it must be version A.03.20 or later.
•
SAN Manager LM is supported on N-Class, V-Class, and L-Class servers, and J-6000
workstations.
•
Each SAN Manager LM host must have at least one A5158A host bus adapter card
installed.
•
Available disk space per file system: root (/): 2 MB and /opt: 500 KB
•
Network adapter
•
Network protocol: TCP/IP
•
You must have at least one HP-UX host on the LAN with a CD-ROM
Table 1
DART 51 Bundles
Bundle ID Version Name
A5158A B.11.00.05 HP PCI Tachyon TL Fibre Channel
B7609BA A.03.20 Event Monitoring Service
