HP StoreEver MSL6480 Tape Library Module Replacement (QU625-96304, June 2013)

You will need a #1 Phillips screwdriver to remove the
drive bay covers and a small flat head screwdriver.
Have several static safe bags available for the boards
being moved to the replacement chassis.
Before beginning this replacement procedure
Ensure that the rack is level side to side and front to
back.
Verify that any applications using the library are idle.
CAUTION: If the temperature in the room
where the replacement module will be installed
varies by 15º C (30º F) from the room where it
was stored, allow it to acclimate to the
surrounding environment for at least 12 hours
before unpacking it from the shipping container.
Saving the configuration settings
Skip this step if you are replacing an expansion
module.
The configuration settings will transfer to the
replacement module when you install the library
module controller. However, HP recommends saving
a backup copy. Refer to the HP StoreEver MSL6480
User and Service Guide for instructions on saving
configuration settings to a USB flash drive or file on
your computer.
Unlocking the magazine
HP recommends unlocking the magazine using the
operator control panel (OCP) or remote management
interface (RMI). If these methods fail, or if a magazine
needs to be removed when the power to the device is
off, you can release the magazine manually.
Using the OCP
1. Log in as an administrator.
2. On the home screen, tap Open Magazine.
3. Tap Unlock in the left or right magazine column
within the module containing the magazine to be
removed.
4. Tap Submit. A message box indicates when the
magazine has been unlocked.
5. Tap OK to close the message. The Open
Magazine screen shows that the magazine is now
unlocked.
NOTE: If not removed, the magazines and the
mailslot will relock after 30 seconds.
Using the manual release
1. Open the magazine access door.
