HP XP P9000 Storage Replcation Adapter 2.0 Administrative Guide

Table 1 RMSRA20 services
Startup typeDisplay nameService name
AutomaticEvent LogEventLog
AutomaticVMware VirtualCenter Servervpxd
AutomaticVMware Site Recovery Manager Servicevmware-dr
• RMXP SRA and Array
“Supported version of RMXP SRA and RAID Manager and microcode” (page 6) shows the
support matrix of the RMXP SRA (rmsra command) and RAID Manager delivered with Micro
code of the Array.
Table 2 Supported version of RMXP SRA and RAID Manager and microcode
Related version
Array microcodeHP XP P9000
RAID Manager
RMSRA20NO
HP (P9000HP XP24000HP XP12000HP XP1024
70-01-XX60-06-XX50-09-XXUnsupported01.24.16 or
later
02.01.031
70-01-XX60-06-XX50-09-XXUnsupported01.24.16 or
later
02.01.042
NOTE: The RMXP SRA20 supports both P9000 and XP24000/12000 array families.XP128/1024
is not supported, because XP128/1024 does not support LUN WWN. ESX Server supports "NAA
version 6 information" in Page 83 SCSI inquiry as UUID. RAID Manager (01.22.06) supports
“LUN WWN” and “Port WWN”.ESX Server and Datastore recognize a Lun using "LUN WWN"
as returned by P9000/XP24000.
RMSRA20 configurations
VMware Site Recovery Manager protects critical virtual machine systems from disasters and
emergencies. Remote Replication Copy provides data protection. SRM requires SRA2.0 . RMSRA20
supports the following the command scripts:
• <Name>queryInfo<Name>
• <Name>queryCapabilities<Name>
• <Name>queryConnectionParameters<Name>
• <Name>queryErrorDefinitions<Name>
• <Name>discoverArrays<Name>
• <Name>discoverDevices<Name>
• <Name>checkTestFailoverStart<Name>
• <Name>checkFailover<Name>
• <Name>failover<Name>
• <Name>testFailoverStart<Name>, <Name>testFailoverStop<Name>
• <Name>syncOnce<Name>
• <Name>querySyncStatus<Name>
• <Name>reverseReplication<Name>
• <Name>restoreReplication<Name>
6 VMware Site Recovery Manager overview
