Virtual Array Installation Guide 37
Installing Command View SDM on HP-UX
Minimum System Requirements for HP-UX
Locating HP-UX Patches
Support Plus Hardware/Critical Patch Bundle information can be found on the
HP-UX Support Plus
CD-ROM, or on the following web page:
http://www.software.hp.com/SUPPORT_PLUS/hwe.html
The latest Java patches for HP-UX can be downloaded from the following web
site:
http://www.hp.com/products1/unix/java/infolibrary/patches.html
Installation Tips
— For the latest information on installing and upgrading the software,
refer to the README file on the
CommandView SDM
Installation CD.
The README is located in the corresponding operating system
directory.
— Make sure EMS hardware monitoring is installed and operating on the
host before installing CommandView SDM. This will ensure that the
Host
■ HP-UX 11.0/11.11 (plus the Support Plus Hardware
Enablement Bundle, version September 2001 or later)
■ RAM: 256 Mbyte
■ Screen Resolution: 800 x 600 (for the GUI)
(Recommended 1024 X 768)
■ Video Support: 64K colors or better
■ Disk Space for Logs: 16 Mbyte per 2 months
■ Disk Space: 60 Mbyte in the /var directory
