10 Virtual Array Installation Guide
Figure 2 VA 7100 Controller Enclosure (D)
1
2
5
6 17
7
10
9
11
12
14
13
15
16
8
4
3
1 - Power/Standby Switch 10 - Array Controller LEDs
2 - System LEDs 11 - RS-232 Connector
3 - Disk Drive 1 (of 15) 12 - Array Controller Card 2
4 - Disk Drive LEDs 13 - AC Power Connector
5 - Disk Drive Slot No. 1 (of 15) 14 - Power Module 1
6 - Front ESD Ground Receptacle 15 - Power Module LEDs
7 - Array Controller Card 1 16 - Power Module 2
8 - HOST FC Connector 17 - Rear ESD Ground Receptacle
9 - HOST FC LEDs
