HP StorageWorks Virtual Array 7000 Family User and Service Guide (January 2005)

96 Servicing & Upgrading
Table 21 Reference Parts
1 A7289-69001 Disk Drive, 146GB, 10k rpm, 512 bytes/sector
(Supported on VA 7110 and VA 7410 only)
10-15 E CRU
2A6198-67002
A6198-67014
Disk Drive Filler Panel (DS 2400)
Disk Drive Filler Panel (DS 2405)
0-5 R CRU
3 A6250-69001 Power Supply/Fan Module 2 E CRU
4 A6214-69001
A6255-69001
Link Controller Card (DS 2400)
Link Controller Card (DS 2405)
2
2
E
E
HP
HP
5A6250-67006
A6490-69002
Midplane Assembly (DS 2400)
Midplane Assembly (DS 2405)
Both include: midplane PCA, T-15 driver, ESD kit,
9 x T-15 x 6/32 x 7/16” long screws,
3 x T-10 x 6mm long screws,
2 x power/ standby switch shaft, 2 x lightpipe)
1RHP
6 A6214-67003 Enclosure Bezel 1 R CRU
Part No. Description
A3231-60030 Rack Rail Kit, HP Computer Cabinet
A6209-60001 Rack Rail Kit, HP Rack System/E
A5635-60001 Rack Rail Kit, Compaq 9000
5181-6639 RS-232 Cable, 9-pin-9-pin, DB9, Null Modem
A3583A 2m SC-SC M/M Fiber Optic Cable
A3531A 16m SC-SC M/M Fiber Optic Cable
A3735A 50m SC-SC M/M Fiber Optic Cable
A3736A 100m SC-SC M/M Fiber Optic Cable
C7524A 2m LC-LC M/M Fiber Optic Cable
C7525A 16m LC-LC M/M Fiber Optic Cable
C7526A 50m LC-LC M/M Fiber Optic Cable
C7527A 100m LC-LC M/M Fiber Optic Cable
C7529A 2m LC-SC M/M Fiber Optic Adapter Cable
C7530A 16m LC-SC M/M Fiber Optic Adapter Cable
C7534A F/F Fiber Optic Coupler
