Servicing & Upgrading 93
Servicing & Upgrading
Figure 32 Controller Enclosure FRUs
Table 19 Controller Enclosure Field Replaceable Units
Fig. 23
Item
Part No. FRU Description
Qty
Per
Encl.
Exch./
Repl.
Part
FRU
Type
1 A6191-69001 Disk Drive, 18GB, 15k rpm, 512 bytes/sector 4-15
1
10-15
2
ECRU
1 A6192-69001 Disk Drive, 36GB, 10k rpm, 512 bytes/sector 4-15
1
10-15
2
ECRU
1 A6194-69001 Disk Drive, 73GB, 10k rpm, 512 bytes/sector 4-15
1
10-15
2
ECRU
1 A7288-69001 Disk Drive, 73GB, 15k rpm, 512 bytes/sector
(Supported on VA 7110 and VA 7410 only)
4-15
1
10-15
2
ECRU
1
2
3
456
7
8
