System/E racks. Field-rackable products are supported in the racks listed in
Table 2.
Table 1 Virtual Array Product Configurations
Table 2 Virtual Array Supported Racks
1
HP Computer Cabinet requires a 1U filler panel to hide the mounting rails.
2
Does not include space that may be required for PDUs.
Model
Enclosure/
Configurations
No. of
Enclosures
Disks
Per Encl.
Controller Cards
Per Encl.
Memory Per
Controller
(in MBytes)
a
a.See Table 25 on page 136 for valid DIMM configurations.
VA 7100 Controller 1 4-15 1 or 2 array controllers
1 Gbit/s
256, 512,
or 1024
VA 7110 Controller 1 4-15 2 array controllers
1 or 2 Gbit/s
1024 or 2048
VA 7400 Controller 1 10-15 2 array controllers
1 or 2 Gbit/s
512 or 1024
VA 7410 Controller 1 10-15 2 array controllers
1 or 2 Gbit/s
1024 or 2048
VA 7110/
7400/7410
Disk 0-6 2-15 2 link controllers
7400: 1 Gbit/s
7410: 2 Gbit/s
N/A
Rack
Product No.
Rack Name
Height
meters/
EIA Units
No. of
EIA Units per
Array
1
No. of
Arrays
per Rack
2
J1500A HP Rack System/E41 1.96 m/ 41 U 3 13
J1501A HP Rack System/E33 1.60 m/ 33 U 3 11
J1502A HP Rack System/E25 1.25 m/ 25 U 3 8
E3660B HP System Rack 1.10 m/ 21 U 4 5
E3661B HP System Rack 1.60 m/ 32 U 4 8
E3662B HP System Rack 1.96 m/ 41 U 4 10
9142 Compaq 9000 Rack 2.0 m/ 42 U 3 14
9136 Compaq 9000 Rack 1.7 m/ 36 U 3 12
9122 Compaq 9000 Rack 1.1 m/ 22 U 3 7
