Servicing & Upgrading 131
Servicing & Upgrading
Midplane Assembly
Note The controller enclosure and the disk enclosure both use the
same midplane assemblies. To remove and replace a midplane
assembly in the disk enclosure, follow the steps under "Removing
a Midplane Assembly" on page 122 and "Installing a Midplane
Assembly" on page 123, except in step 3, you will disengage
(when removing) or re-engage (when installing) the LCCs. See
"Removing an LCC" on page 127.
