Servicing & Upgrading 97
Servicing & Upgrading
Hot Swappable FRUs
A field replaceable unit (FRU) is “hot swappable” if it can be removed and
replaced while the array is powered on, without disrupting I/O activity. A FRU
is
not
hot swappable if all applications and file systems must be terminated, or
a host shutdown must be performed, before it can be replaced. Table 22 shows
hot swappable FRUs for the controller enclosure and the disk enclosure.
Table 22 Hot Swappable FRUs
*Only if the OS supports controller failover.
Enclosures FRU
Hot
Swappable
Controller & Disk Disk Drive Yes
Controller & Disk Power Module Yes
Controller Single Controller No
Controller Dual Controller Yes*
Controller (VA 7100 Only) GBIC Yes*
Controller & Disk Fiber Optic Cables Yes*
Disk LCC Yes
Controller & Disk Midplane Assembly No
