HP StorageWorks Virtual Array 7000 Family User and Service Guide (January 2005)

94 Servicing & Upgrading
1
VA 7100
2
VA 7110/7400/7410
3
Per controller
4
When replacing a failed A6211-69001 power supply, both supplies
should be replaced with the newer A6211-69002. The A6211-69002 is
not certified to operate with the A6211-69001 in the same array enclosure
for an extended period of time. To ensure proper array operation, the
power supplies should not be mixed in the same array.
1 A7289-69001 Disk Drive, 146GB, 10k rpm, 512 bytes/sector
(Supported on VA 7110 and VA 7410 only)
10-15
2
ECRU
2 A6198-67002 Disk Drive Filler Panel 0-11
1
0-5
2
RCRU
3A6211-69002Power Module
4
2ECRU
4 A6188-69005
A7293-69203
A6189-69103
A6218-69304
VA 7100 Controller
VA 7110 Controller
VA 7400 Controller
VA 7410 Controller
(All controllers include a battery)
1 or 2 E HP
REF A6185-67001 256 MB DIMM (used on item 4)
(VA 7100 and VA 7400 only)
1 or 2
3
RHP
REF A6186-67003 512 MB DIMM (used on item 4; order two for
1024 MB configuration)
1 or 2
3
RHP
REF A6200-69001 1024 MB DIMM (used on item 4; order two for
2048 MB configuration)
1 or 2
3
RHP
REF A6188-67002 Battery Kit (includes: Li-Ion battery & battery
clamp; used on item 4)
1
3
RCRU
5 A6197-67001 Array Controller Filler Panel 0 or 1 R CRU
6 A6203-67001 GBIC, optical shortwave 1
3
RCRU
7 A6183-69006 Midplane Assembly (includes: midplane PCA,
T-15 driver, ESD kit,
9 x T-15 x 6/32 x 7/16” long screws,
3 x T-10 x 6mm long screws,
2 x power/ standby switch shaft, 2 x lightpipe)
1RHP
8A6183-67001Enclosure Bezel 1 R CRU
