70 System Configurations
Highly Redundant Cluster (VA 7410)
Array
Controller 1
Controller 2
Host
HBA
HBA
Switch
Switch
Host
HBA
HBA
Requires fabric login
Requires LUN security support
Requires dual HBAs
Dual controllers
Requires LUN Security support
Requires multi-path driver (Windows
2000 and HP-UX only)
SAN Manager software recommended
Command View SDM required on one
of the hosts
