HP Storageworks Storage Mirroring Console user's guide (T2558-96330, April 2009)

6 - 9
Source Server and Target Server
Replication Status
 Replicating—Data is being replicated from the source to the target.
 Pending—Replication is pending.
 Stopped—Replication has been stopped.
 Out of Memory—Replication memory has been exhausted.
 Unknown—Cannot determine the replication status.
Replication Queue The total number of replication bytes that are in the source queue.
Disk Queue The number of bytes of disk space being used to queue data on the source.
Bytes Sent The total number of mirror and replication bytes that have been transmitted
from the source to the target.
Bytes Sent
(Compressed)
The total number of compressed mirror and replication bytes that have been
transmitted to the target. If compression is disabled, this statistic will be the
same as Bytes Sent.
Statistic Description
Name Name of the server.
Activity What Storage Mirroring is currently doing on the server.
Status State of the client communication to the server. Status may be:
 Connecting—Storage Mirroring Console is trying to establish
communication.
 Online—Server is online.
 Offline—Server is offline.
 Failed—Server was recently online but communication has been lost.
View server details Click this link to open the View server details page. For more information,
see Viewing server details on page 7-5.
Statistic Description
