HP Storageworks Storage Mirroring Console user's guide (T2558-96330, April 2009)

6 - 6
Connection Details Summary
Viewing connection details
On the View Connection Details page, you can view detailed information about a connection.
1. Navigate to the Monitor Connections page by either clicking the Monitor Connections button
on the main toolbar, or selecting Go, Monitor connections.
2. Select a connection.
Reverse protection—Select a protection that has already failed over, then click
the Reverse protection button to start the protection in the reverse direction.
The job will start synchronization in the reverse direction. The job name and the
log file name will change accordingly. When the restore completes, the job will be
running in the opposite direction (that is, if the job had originally be running from
server
Indy to server Jersey, it will now be running from server Jersey to
server
Indy).
View protection error—If the selected protection has encountered any error
conditions, click this button to view the most recent error associated with the
protection job.
Statistic Description
Name Name of the server.
Activity What Storage Mirroring is currently doing on the server.
Source Server The name of the source.
Target Server The name of the target.
Bytes Sent The total number of mirror and replication bytes that have been transmitted
from the source to the target.
Bytes Sent
(Compressed)
The total number of compressed mirror and replication bytes that have been
transmitted to the target. If compression is disabled, this statistic will be the
same as Bytes Sent.
Connected Since The date and time when the current connection was made.
Protection Type The type of protection task.
Protection Status The current status of the protection job.
Protected Volumes The volume(s) selected to be protected.
Target Path The volume on the target where the replica virtual machine is stored.
Automatic Failover Whether automatic failover has been enabled for the connection.
Toolbar
Button
Description
