HP StorageWorks XP Performance Advisor Software v4.6 Install Guide (T1789-96096, July 2010)

For the XP24000/XP20000/XP12000/XP10000 disk arrays, configure the command devices as
SLPR0 to report full Storage Logical Partition (SLPR) data.
NOTE:
For further assistance, contact HP technical support.
Launching Command View XP AE
Complete the following steps before launching the XP RWC:
1. Launch the Command View XP AE Device Manager by typing http://<ip_address>:23015/
DeviceManager/ into a browser window.
NOTE:
If you are using a secured connection, the port number will be different and the URL will be in
the following format:
http://<ip_address>:23016/DeviceManager/
2. In the Login window, enter the user name as system and the password as manager, and click
Login.
3. In the Command View XP AE Device Manager window, click the Resources tab in the CV AE
Device Manager Explorer navigation pane.
4. Click the Subsystems node and select the subsystem for which you want to create the command
device. (The individual subsystems are displayed in the Subsystems navigation pane, which is
on the right side of the Explorer navigation pane.)
5. Click Physical View to launch the XP RWC with administrator privileges (that is, administrator\ad-
ministrator).
6. In the XP RWC window, click GO > LUN Manager > LU Path and Security. A list of LDEVs appears.
7. Right-click the LDEV that you want to convert into a command device.
8. Select Enable\Disable from the drop down list.
9. Click Apply to save the changes and enable the selected LDEV as a command device.
Creating a command device using XP RWC for XP24000, XP20000, XP12000, and XP10000
disk arrays
Complete the following steps to create a command device:
1. Launch the XP RWC with administrator privileges (administrator\administrator).
2. In the XP RWC window, click GO > LUN Manager > LU Path and Security. A list of LDEVs appears.
3. Right-click the LDEV that you want to convert into a command device.
4. Select Enable\Disable from the drop down list.
5. Click Apply to save the changes and enable the selected LDEV as a command device.
Understanding the XP Performance Advisor installation prerequisites36
