7. Select the check box for Stagger Schedule if you want to stagger the data collection time at
different intervals.
The Stagger Schedule ensures that the load on the management server at any point is balanced,
because data collection occurs for all XP disk arrays at varied points of time in the day and not
every 15 minutes of the hour.
8. Select the Add new RAID Groups, Ports to this schedule check box, if you want the performance
data collection schedule to automatically collect performance data for the new RAID groups or
ports that are discovered during scheduled configuration data collection. If the Add new RAID
Groups, Ports to this schedule check box is selected in the first schedule, it is automatically disabled
in the second schedule.
However, the new THP, Snapshot, XP Continuous Access Journal volumes, and External RAID
groups are automatically added to only that performance data collection schedule, which is
already collecting data for other virtual volumes belonging to the same XP Disk Array.
9. Click Save for the changes to take effect.
Click Cancel, if you do not want to configure a schedule for the current selection.
10. Click Refresh to view the updated list of performance data schedules.
The new schedule starts automatically and XP Performance Advisor starts collecting data for the
selected resources. The following table provides the subsequent changes that occur in the Performance
Data section for the selected XP Disk Array record:
DescriptionScreen elements
Displays the new schedule name.
Schedule Name
Displays the selected resources. Click View to see the corresponding schedule
details.
Components
Displays , which indicates that the schedule has started.
Initially, displays when a schedule is not yet configured, or stopped.
Enabled
Displays the selected frequency for DKC, RG, and Port data collection.
Initially, displays 0,0,0 when a schedule is not yet configured.
Frequency
Allow XP Performance Advisor to complete at least two performance data collection cycles before
you proceed with other related activities, such as generating reports and plotting charts.
