5. In the respective resource type lists, select the check boxes for resources to collect their performance
data. The following resource type lists are displayed:
• DKC
• Port
• RAID Groups
• THP Groups
• Snap Groups
• CA Journal Groups
• External RAID Groups
NOTE:
• Selecting a ThP, Snapshot, or XP Continuous Access Journal volumes also provides the
respective volume pool information.
• The THP Groups, CA Journal Groups, and Snap Groups resource type lists are displayed
only if the corresponding resources are configured on the selected XP Disk Array. The
External RAID Groups resource type list is displayed only if external volumes are attached
to the selected XP Disk Array.
• Select the Select All check box in a particular resource type list box, if you want all the
corresponding resources to be selected. The Select All check box is provided for each
resource type list.
Figure 19 Performance Data Collection
.
Resource type list.1
6. Set the frequency in minutes for DKC, RG, and Port performance data collection by selecting the
frequency from the respective Frequency list.
