HP StorageWorks 1510i Modular Smart Array iSCSI concepts and deployment guide (431338-002, July 2008)

Network Time Protocol
(NTP) is not working
• No route to NTP server from MSA1510i management port.
• Wrong IP address entered for NTP server.
• NTP is not enabled on the Windows Server via the group policy editor.
Error message on the
front panel L
CD
• See the MSA15
10i Maintenance and Service Guide.
Graphics in the Storage
Management Utility are
not animated
• Enable animations to play in Internet Explorer’s Internet Options.
Poor performance
• Degraded mode arrays or array rebuild.
• Too many initiators attached to the MSA1510i.
• Low quality components in the network path, including NICs and IP switches
that are not capable of gigabit operations.
• Low-quality cables.
Controll
ers failover
repeate
dly and do not
stop
• Two servers are connected to opposing controllers without a common data
path. Reasons could include, failed network path, lack of login, or disabled
ports.
Server logs into target
correctly and LUNs
are displayed in the
Disk Manager with a
partition, but no drive
letters appear
• TheLUNmayhavebeenapartofanotherserverandmigratedtothe
MSA1510i. Assign a drive letter and restart Disk Manager. The LUN should
now be manageable.
LUNs show in Disk
Manager but are listed
as unavailable; all Disk
Manager operations fail
• The DSM may not be loaded and login occurred on standby controller.
Telnet or SSH terminates
the connection
spontaneously
• A failover may have occurred on the controller pair. Each time a failover
occurs, the connection is lost and a new connection must be established with
the management port.
Target login fails to
complete on shared
M SA 1510 i
• The number of target logins is limited to 32 per controller. Verify that the limit
has not been reached by executing show tgt_stats on each target, adding
up the total number of sessions up.
iSCSI configuration was
lost during a MSA1510i
chassis swap out
• All iSCSI information is tied to the serial number of the device. Swapping
chassis results in a change in the serial number.
Sudden loss in
connectivity with
target/LUN
• Duplicate IP address on the network.
• Failure of network path.
• Use of DHCP for server IP addresses.
Reinserted controller fails
to start up
• Reinsertion of a controller within ten seconds of removal may lead to the
failure of the other controller. Allow more than ten seconds between removal
and reinsertion.
1510i Modular Smart Array iSCSI concepts and deployment guide
49
