5 Available monitoring tools
The MSA1510i is unique in the MSA product family with its integrated configuration utilities and
management agents. This section describes the confi guration options of these integrated utilities and
agents, including:
• HP Systems Insight Manager (HP-SIM)
•SNMPservicesettings
• Ethernet network trafficorprotocolanalyzer
HP Systems Insight Manager
HP Systems Insight Manager (HP-SIM) is useful for managing and monitoring a large number of systems. It
acts as a collection point for SNMP traps and can periodically sweep the network to discover new systems.
HP-SIM registers the MSA1510i through either automatic discovery by a ping sweep or by manual entry
of the MSA1510i management IP address. HP-SIM 4.2 or later can recognize the MSA1510i as a storage
device. For older versions of HP-SIM, you may add the MSA1510i to the list of known system types by
creating a
rule to match the MSA1510i system object identifier: 1.3.6.1.4.1.11.2.3.9.13.2
HP-SIM is i
ncluded on the HP Management CD shipped with all ProLiant servers. For more information
see the HP-
SIM website: h
ttp://www.hp.com/go/sim.
SNMP service settings
An SNMP management system, such as HP Systems Insight Manager (HP-SIM), can read the MIBs in the
MSA1510i if the community string matches. Set the community string as appropriate. The MSA1510i
supports sending SNMP traps to up to four destinations, as long as the community strings match.
Traps that the MSA1510i can send include:
Community string
Trap value
SS2_TRA
P_TEMP_STATUS_CHANGE 8019
SS2_TRAP_FAN_STATUS_CHANGE
8020
SS2_TRAP_POWER_SUPPLY_STATUS_CHANGE
8021
SS2_TR
AP_BACKPLANE_FAN_STATUS_CHANGE 8022
SS2_TRAP_BACKPLANE_TEMP_STATUS_CHANGE
8023
SS2_TRAP_BACKPLANE_POWER_SUPPLY_STATUS_CHANGE 8024
FCA_TR
AP_SPARE_STATUS_CHANGE 16002
FCA_TRAP_ARRAY_ACTIVE 16014
FCA_TRAP_PHYSDRV_STATUS_CHANGE
16016
FCA_T
RAP_ACCEL_STATUS_CHANGE 16017
FCA_TRAP_ACCEL_BAD_DATA
16018
FCA_TRAP_ACCEL_BATTERY_FAILED
16019
FCA_T
RAP_ARRAY_STATUS_CHANGE 16020
FCA_TRAP_EXT_LOGDRV_STATUS_CHANGE
16022
