3MSA1510iconfiguration options
and samples
Included in this section:
•Configuration options
•Configuration rules
•Configuration variables
•Exampleconfigurations
Configurati
on options
Basic configurations Advanced configurations
Number of MS
A controllers
One
Dual
Storage traffic
On a single LAN segment.
Separated into multiple LAN
segments by using VLAN tags to
isolate traffic.
Number of defined iSCSI targets
One
Multiple
Number of p
ortal groups used by
each iSCSI
target
One
Multiple
Number of portals per portal
group
One
Multiple
TCP portal values
The default, well-known value. The
default TCP port for iSCSI is 3260.
User-defined values.
Digests
Disabled Enabled
Access Control Lists (ACLs) Disabled Enabled
CHAP authentication Disabled Enabled
SSL cert
ificate
Use the MSA1510i self-signed
certific
ate. A security warning is
displayed when first accessing
the SMU on an SSL-protected
connection.
APEMcertificate was uploaded
totheMSA1510i. Seethe
Storage Management Utility user
documents for instructions.
Network Time Protocol (NTP) Not used Used
SNMP community strings
Not used
Used — if the SNMP community
string matches, a management
tool, such as HP-SIM can read
status via SNMP from the
MSA1510i management port.
SNMP
traps
Not used
Used —
if the MSA1510i is
confi
gured to send SNMP traps
to a m
anagement system such as
HP-SIM, event notifications are
sent directly to the management
system.
