HP StorageWorks Modular Smart Array 1000 Configuration Procedures for HP-UX Addendum (365448-001, April 2004)

Fibre Channel switched fabric deployments
4 Modular Smart Array 1000 Configuration Procedures - for HP-UX Addendum
The following is an example of the information included in the ioscan and a
sample completed table:
Class I H/W Path Driver State H/W Type Description
------- - ------------------------ --------- -------- ---------- -----------------------------
ba 2 0/2 lba CLAIMED BUS_NEXUS Local PCI Adapter (782)
fc 1 0/2/0/0 fcd CLAIMED INTERFACE HP 2Gb Dual Port PCI/PCI-X
Fibre Channel Adapter (Port 1)
/dev/fcd1
fcp 0 0/2/0/0.4 fcd_fcp CLAIMED INTERFACE FCP Domain
ext_bus 4 0/2/0/0.4.11.0.0 fcd_vbus CLAIMED INTERFACE
target 8 0/2/0/0.4.11.0.0.1 tgt CLAIMED DEVICE
disk 4 0/2/0/0.4.11.0.1.7 sdisk CLAIMED MSA1000 VOLUME
/dev/dsk/c4t1d7 /dev/rdsk/c4t1d7
target 9 0/2/0/0.4.11.0.0.2 tgt CLAIMED DEVICE
disk 5 0/2/0/0.4.11.0.1.2.5 sdisk CLAIMED MSA1000 VOLUME
/dev/dsk/c4t2d5 /dev/rdsk/c4t2d5
.
.
.
ext_bus 5 0/2/0/0.4.11.255.0 fcd_vbus CLAIMED INTERFACE FCP Device Interface
target 7 0/2/0/0.4.11.255.0.0 tgt CLAIMED DEVICE
ctl 4 0/2/0/0.4.11.255.0.0.0 sctl CLAIMED DEVICE MSA1000
/dev/rscsi/c5t0d0
Table 2: Sample Information Table for this System with one HBA and one MSA1000 Controller
Class H/W Path
DSF
Driver WWPN Description
fc 0/2/0/0
/dev/fcd1
fcd 50060b00 001188da HP 2Gb Dual Port PCI/PCI-X
Fibre Channel Adapter (Port
1)
ctl
0/2/0/0.4.11.255.0.0.0
/dev/rscsi/c5t0d0
sctl 500805f3 0008aab0 MSA1000
MSA1000 controller firmware filename and path: /tmp/scu/msav430b285.bin
