3–4 HSG80 ACS Solution Software Version 8.6 for IBM AIX Installation and Configuration Guide
Figure 3–2. Single-Bus Enterprise Storage RAID Array Storage System
5. Connect the AC power cords from the appropriate rack AC outlets to the controller and
disk enclosures.
1 SCSI Bus 1 Cable 2 SCSI Bus 2 Cable
3 SCSI Bus 3 Cable 4 SCSI Bus 4 Cable
5 SCSI Bus 5 Cable 6 SCSI Bus 6 Cable
7 AC Power Inputs 8 Fibre Channel Ports
1
8
2
3
6
CXO7382A
4
5
7
