Chapter 3
Preparing the Host System
This chapter describes how to prepare your IBM AIX host computer to accommodate the
HSG80 controller storage subsystem.
The following information is included in this chapter:
■ “Enterprise Storage RAID Array Storage System Installation,” page 3–1
■ “Making a Physical Connection,” page 3–5
■ “Storage Works Platform Kit Installation,” page 3–6
Enterprise Storage RAID Array Storage
System Installation
WARNING: A shock hazard exists at the backplane when the controller enclosure
bays or cache module bays are empty.
Be sure the enclosures are empty, then mount the enclosures into the rack. DO NOT
use the disk enclosure handles to lift the enclosure. The handles cannot support the
weight of the enclosure. Only use these handles to position the enclosure in the
mounting brackets.
Use two people to lift, align, and install any enclosure into a rack. Failure to use two
people might cause personal injury and/or equipment damage.
