Planning Storage 2–9

Figure 2–6. PTL addressing in a dual-bus configuration, three Model 4354R disk enclosures

Model 4354R Disk Enclosure Shelf 1 (dual-bus)

SCSI Bus A SCSI Bus B

Bay 1234567891011121314

SCSI ID 00 01 02 03 04 05 08 00 01 02 03 04 05 08

DISK ID

Disk10000

Disk10100

Disk10200

Disk10300

Disk10400

Disk10500

Disk10800

Disk20000

Disk20100

Disk20200

Disk20300

Disk20400

Disk20500

Disk20800

Model 4354R Disk Enclosure Shelf 2 (dual-bus)

SCSI Bus A SCSI Bus B

Bay 1234567891011121314

SCSI ID 00 01 02 03 04 05 08 00 01 02 03 04 05 08

DISK ID

Disk30000

Disk30100

Disk30200

Disk30300

Disk30400

Disk30500

Disk30800

Disk40000

Disk40100

Disk40200

Disk40300

Disk40400

Disk40500

Disk40800

Model 4354R Disk Enclosure Shelf 3 (dual-bus)

SCSI Bus A SCSI Bus B

Bay 1234567891011121314

SCSI ID 00 01 02 03 04 05 08 00 01 02 03 04 05 08

DISK ID

Disk50000

Disk50100

Disk50200

Disk50300

Disk50400

Disk50500

Disk50800

Disk60000

Disk60100

Disk60200

Disk60300

Disk60400

Disk60500

Disk60800
