1–22 HSG80 ACS Solution Software Version 8.6 for IBM AIX Installation and Configuration Guide
Figure 1–12 shows the placement of the worldwide name label for the Model 2200
enclosure, and Figure 1–13 for the BA370 enclosure.
Figure 1–12. Placement of the worldwide name label on the Model 2200 enclosure
Figure 1–13. Placement of the worldwide name label on the BA370 enclosure
CAUTION: Each subsystem has its own unique worldwide name (node ID). If you
attempt to set the subsystem worldwide name to a name other than the one that
came with the subsystem, the data on the subsystem will not be accessible. Never set
two subsystems to the same worldwide name, or data corruption will occur.
1 Node ID
(Worldwide name)
2 Checksum
CXO7228A
WWN INFORMATION
P/N:
WWN:
Checksum:
NNNN – NNNN – NNNN – NNNN
NN
S/N:
1
2
1 Node ID
(Worldwide name)
2 Checksum
CXO6873B
WWN INFORMATION
P/N:
WWN:
Checksum:
NNNN – NNNN – NNNN – NNNN
NN
S/N:
1
2
