About this Guide xxi
Figure 2. Configuring storage with the CLI
Create Storagesets
and Partitions:
Stripeset, Page 5-17
Mirrorset, Page 5-17
RAIDset, Page 5-18
Striped Mirrorset, Page 5-17
Single (JBOD) Disk, Page 5-19
Partition, Page 5-20
Assign Unit Numbers
Page 5-21
Continue creating units
until you have you have
completed your planned
configuration.
Add devices
Page 5-16
Configuration Options
Page 5-22
Verify Storage Setup
Chapter 6
A
