C–4 HSG80 ACS Solution Software Version 8.6 for IBM AIX Installation and Configuration Guide
For dual host connection configurations, the S value for the hdisk location code is zero.
However, any hdisks, associated with the D0XX and D1XX series of storage system
units, is distinguished by their host adapter associations. As a consequence, the CCL,
by its host designation, determines the series.
The following figure is an example of dual host:
Figure C–2. RAID set units in a dual host
From this result, D001 and D102 are the target unit drives for copy in the storage
system.
# lsdev –Cc disk
hdisk0 Available 10-60-00-8,0 16 Bit SCSI Disk Drive
hdisk1 Available 20-60-00-4,0 Other SCSI Disk Drive
hdisk2 Available 30-60-00-0,0 DEC HSG80 RAID Array
hdisk3 Available 40-60-00-0,0 DEC HSG80 Command Console LUN
hdisk4 Available 30-60-00-0,1 DEC HSG80 RAID Array
hdisk5 Available 30-60-00-0,2 DEC HSG80 RAID Array
hdisk6 Available 40-60-00-0,1 DEC HSG80 RAID Array
hdisk7 Available 40-60-00-0,2 DEC HSG80 RAID Array
hdisk8 Available 40-60-00-0,3 DEC HSG80 RAID Array
hdisk9 Available 40-60-00-0,4 DEC HSG80 RAID Array
#
1
2
3
1 Target hdisks from lsvg command.
2 The CCL (hdisk3) is the same host adapter as hdisk6. The
L value for hdisk6 is 1, therefore the RAID set unit
number is D001.
3 Since hdisk5 host adapter string does not match the CCL
and the L value is 2, the RAID set unit number for hdisk5
is D102.
