Exploitation of the CLONE and SNAPSHOT Functions of the HSG80 in an AIX Environment C–3
The following figure is an example of identifying the RAID set units in a single
host configuration using datavg as a hypothetical volume group.
Figure C–1. RAID set units in a single host
# lsvg –p datavg
datavg:
PV_NAMEPV STATETOTAL PPsFREE PPsFREE DISTRIBUTION
hdisk5active5422200..00..00..00..22
hdisk6active5422300..00..00..00..23
# lsdev –Cc disk
hdisk0 Available 10-60-00-8,0 16 Bit SCSI Disk Drive
hdisk1 Available 20-60-00-4,0 Other SCSI Disk Drive
hdisk2 Available 30-60-00-0,0 DEC HSG80 RAID Array
hdisk3 Available 30-60-00-1,0 DEC HSG80 Command Console LUN
hdisk4 Available 30-60-00-0,1 DEC HSG80 RAID Array
hdisk5 Available 30-60-00-0,2 DEC HSG80 RAID Array
hdisk6 Available 30-60-00-1,1 DEC HSG80 RAID Array
hdisk7 Available 30-60-00-1,2 DEC HSG80 RAID Array
hdisk8 Available 30-60-00-1,3 DEC HSG80 RAID Array
hdisk9 Available 30-60-00-1,4 DEC HSG80 RAID Array
4
1
2
3
1 Target hdisks from lsvg command.
2 The CCL (hdisk3) is the same host adapter as hdisk5 and hdisk6.
3 The S value for hdisk6 is the same as the CCL. The L value for hdisk6
is 1 therefore the RAID set unit number is D001.
4 Since the S value is not same as the CCL and the L value is 2, the RAID
set unit number for hdisk5 is D102.
