Configuration Example Using CLI 7–7
SHOW CONNECTIONS
RENAME !NEWCON02 TAN1B2
SET TAN1B2 OPERATING_SYSTEM=WINNT
SET TAN1B2 UNIT_OFFSET=120
SHOW CONNECTIONS
Mark or tag both end of Fibre Channel cables.
RUN CONFIG
ADD RAIDSET R1 DISK10000 DISK20000 DISK30000 DISK40000 DISK50000 DISK60000
INITIALIZE R1
ADD UNIT D102 R1 DISABLE_ACCESS_PATH=ALL
SET D102 ENABLE_ACCESS_PATH=PURPLE1A1
ADD RAIDSET R2 DISK10100 DISK20100 DISK30100 DISK40100 DISK50100 DISK60100
INITIALIZE R2
ADD UNIT D120 R2 DISABLE_ACCESS_PATH=ALL
Connection
Name
Operating
System Controller Port Address Status
Unit
Offset
!NEWCON02 WINNT THIS 2 XXXXXX OL this 100
HOST_ID=XXXX-XXXX-XXXX-XXXX ADAPTER_ID=XXXX-XXXX-XXXX-XXXX
PURPLE1A1 WINNT OTHER 1 XXXXXX OL other 0
HOST_ID=XXXX-XXXX-XXXX-XXXX ADAPTER_ID=XXXX-XXXX-XXXX-XXXX
WHITE1B2 WINNT THIS 2 XXXXXX OL this 100
HOST_ID=XXXX-XXXX-XXXX-XXXX ADAPTER_ID=XXXX-XXXX-XXXX-XXXX
Connection
Name
Operating
System Controller Port Address Status
Unit
Offset
PURPLE1A1 WINNT OTHER 1 XXXXXX OL other 0
HOST_ID=XXXX-XXXX-XXXX-XXXX ADAPTER_ID=XXXX-XXXX-XXXX-XXXX
WHITE1B2 WINNT THIS 2 XXXXXX OL this 100
HOST_ID=XXXX-XXXX-XXXX-XXXX ADAPTER_ID=XXXX-XXXX-XXXX-XXXX
TAN1B2 WINNT THIS 2 XXXXXX OL this 120
HOST_ID=XXXX-XXXX-XXXX-XXXX ADAPTER_ID=XXXX-XXXX-XXXX-XXXX
