7–6 HSG80 ACS Solution Software Version 8.6 for IBM AIX Installation and Configuration Guide
Mark or tag both ends of Fibre Channel cables.
Plug in the Fibre Channel cable from the second adapter in host “WHITE.”
SHOW CONNECTIONS
NOTE: The offset for !NEWCONO1 is automatically set to 100 because it is plugged into host
port 2.
RENAME !NEWCON01 WHITE1B2
SET WHITE1B2 OPERATING_SYSTEM=WINNT
SHOW CONNECTIONS
Mark or tag both end of Fibre Channel cables.
Plug in the Fibre Channel cable from the adapter in host “TAN”.
Connection
Name
Operating
System Controller Port Address Status
Unit
Offset
RED1A1 WINNT OTHER 1 XXXXXX OL other 0
HOST_ID=XXXX-XXXX-XXXX-XXXX ADAPTER_ID=XXXX-XXXX-XXXX-XXXX
Connection
Name
Operating
System Controller Port Address Status
Unit
Offset
!NEWCON01 WNNT THIS 2 XXXXXX OL this 100
HOST_ID=XXXX-XXXX-XXXX-XXXX ADAPTER_ID=XXXX-XXXX-XXXX-XXXX
PURPLE1A1 WINNT OTHER 1 XXXXXX OL other 0
HOST_ID=XXXX-XXXX-XXXX-XXXX ADAPTER_ID=XXXX-XXXX-XXXX-XXXX
Connection
Name
Operating
System Controller Port Address Status
Unit
Offset
PURPLE1A1 WINNT OTHER 1 XXXXXX OL other 0
HOST_ID=XXXX-XXXX-XXXX-XXXX ADAPTER_ID=XXXX-XXXX-XXXX-XXXX
WHITE1B2 WINNT THIS 2 XXXXXX OL this 100
HOST_ID=XXXX-XXXX-XXXX-XXXX ADAPTER_ID=XXXX-XXXX-XXXX-XXXX
