Configuration Example Using CLI 7–5
SET THIS SCSI_VERSION=SCSI-2
SET THIS ALLOCATION_CLASS=0
RESTART OTHER
RESTART THIS
SET THIS TIME=10-Mar-2001:12:30:34
RUN FRUTIL
Y
Plug serial cable from maintenance terminal into bottom controller.
NOTE: Bottom controller (B) becomes “this” controller.
RUN FRUTIL
Y
SET THIS MIRRORED_CACHE
NOTE: This command causes the controllers to restart.
SET THIS PROMPT=“HLNDR BOTTOM”
SET OTHER PROMPT=“HLNDR TOP”
SHOW THIS
SHOW OTHER
Plug in the Fibre Channel cable from the adapter in host “PURPLE.”
SHOW CONNECTIONS
RENAME !NEWCON00 PURPLE1A1
SET PURPLE1A1 OPERATING_SYSTEM=WINNT
SHOW CONNECTIONS
NOTE: Connection table sorts alphabetically.
Do you intend to replace this controller's cache battery? Y/N [Y]
Do you intend to replace this controller's cache battery? Y/N [Y]
Connection
Name
Operating
System Controller Port Address Status
Unit
Offset
!NEWCON00 WNNT THIS 1 XXXXXX OL this 0
HOST_ID=XXXX-XXXX-XXXX-XXXX ADAPTER_ID=XXXX-XXXX-XXXX-XXXX
