5–16 HSG80 ACS Solution Software Version 8.6 for IBM AIX Installation and Configuration Guide
21. Rename the connections to something meaningful to the system and easy to remember.
For example, to assign the name ANGEL1A1 to connection !NEWCON01, enter:
HSG > RENAME !NEWCON01 ANGEL1A1
Compaq recommends using a naming convention, see “Naming Connections,” page
1–11.
22. Specify the operating system for the connection:
HSG > SET ANGEL1A1 OPERATING_SYSTEM=WINNT
IMPORTANT: Although an IBM operating system entry exists in the CLI and SWCC, for the Fibre
Channel connection, use the default setting WINNT for operation with your IBM host. The IBM
setting may cause problems when LUNs are not available to AIX or during controller failover.
23. Verify the changes:
HSG > SHOW CONNECTIONS
Mark or tag all Fibre Channel cables at both ends for ease of maintenance.
Repeat Procedure for Each Host Adapter Connection
24. Repeat steps 21, 22, and 23 for each of that adapter’s host connections or delete the
unwanted connections from the table.
25. For each host adapter, repeat steps 20 through 24.
Configuring Devices
The disks on the device bus of the HSG80 can be configured manually or with the
CONFIG utility. The CONFIG utility is easier. Invoke CONFIG with the following
command:
RUN CONFIG
CONFIG takes about two minutes to discover and to map the configuration of a
completely populated storage system.
