Configuration Procedures 5–9
For an explanation about why there may be multiple connections shown for one
adapter, see page 1–11.
21. Rename the connections to something meaningful to the system and easy to remember.
For example, to assign the name ANGEL1A1 to connection !NEWCON01, enter:
RENAME !NEWCON01 ANGEL1A1
For a recommended naming convention, see “Naming Connections,” page 1–11.
22. Specify the operating system for the connection:
SET ANGEL1A1 OPERATING_SYSTEM=WINNT
IMPORTANT: Although an IBM operating system entry exists in the CLI and SWCC, for the Fibre
Channel connection, use the default setting WINNT for operation with your IBM host. The IBM
setting may cause problems when LUNs are not available to AIX or during controller failover.
23. Verify the changes:
SHOW CONNECTIONS
Mark or tag all Fibre Channel cables at both ends for ease of maintenance.
Repeat Procedure for Each Host Adapter
24. Repeat step 21, 22, and 23 for each of that adapter’s host connections, or delete the
unused connections from the table.
25. For each host adapter, repeat steps 20 through 24.
Connection
Name
Operating
System Controller Port Address Status
Unit
Offset
!NEWCON00 WNNT OTHER 1 200613 OL other 0
HOST_ID=XXXX-XXXX-XXXX-XXXX ADAPTER_ID=XXXX-XXXX-XXXX-XXXX
