Configuration Procedures 5–5
Configure Controller Settings
3. Check the configuration (parameter settings) of your controller against those listed in
Table 5–1, which are the correct HSG80 controller parameter settings for an IBM-AIX
environment.
NOTE: Setting the SCSI version to SCSI-3 does not make the controller fully compliant with all
SCSI-3 standards. Compaq recommends SCSI-2 mode at this time.
4. Assign an identifier for the communication LUN (also called the command console
LUN, or CCL). The CCL must have a unique identifier that is a decimal number in the
range 1 to 32767, and which is different from the identifiers of all units. Use the
following syntax:
SET THIS IDENTIFIER=N
Identifier must be unique among all the controllers attached to the fabric within the
specified allocation class.
Set This Controller
5. Change any controller parameter settings inconsistent with those in Table 5–1 by
entering the appropriate command for that parameter, as described in the following
steps.
NOTE: After completing all of the required parameter changes, you must restart the controller
for the new settings to take effect.
Ignore the Restart Controller messages until you have finished making all the required
configuration parameter changes.
Table 5–1 Correct Controller Parameter Settings
HSG80 Parameter Settings for: Loop Fabric
Prompt HSG80> HSG80>
Node (WWN) nnnn-nnnn-nnnn-nnnn nnnn-nnnn-nnnn-nnnn
Command Console LUN Enabled Enabled
Port 1 Topology LOOP HARD FABRIC
Port 2 Topology LOOP HARD FABRIC
Port 1 ALPA D5 N/A
Port 2 ALPA D6 N/A
SCSI Version SCSI-2 SCSI-2
New Connection OS Type WINNT WINNT
