Installing and Configuring the HS-Series Agent 4–29
Table 4–5 HACMP Event Scripts
HACMP Event Script Action Required Appended to Event Script by
HACMP_install.sh
Node_down_local Always stop Agent on local node ./”$STEAMDIR/BIN/”SWCC_AG_
STOP_LOCAL.SH
Node_down_remote (none) (nothing)
Node_up_local Check for Agent running on any
node and start Agent on local
node if not already running
./”$STEAMDIR/BIN/”SWCC_AG_
START_LOCAL.SH
Node_up_remote (none) (nothing)
Node_down_local_complete Check for SWCC Agent running
on local node and only issue this
event after agent is stopped on
local node
./”$steamdir/bin/”SWCC_ag_cH
ECK_LOCAL.SH
Node_down_remote_complete Check for Agent running on any
node
./”$steamdir/bin/”SWCC_ag_cH
ECK_ALL.SH
Node_up_local_complete Check for Agent running on any
node and start Agent on local
node if not already running
./”$steamdir/bin/”SWCC_ag_sT
ART_LOCAL.SH
Node_up_remote_complete (none) (nothing)
Acquire_aconn_service (none) (nothing)
Acquire_service_addr (none) (nothing)
Acquire_takeover_addr Check for Agent running and
start it if not running
./”$steamdir/bin/”SWCC_ag_sT
ART_LOCAL.SH
Start_server Check for Agent running on any
node and start Agent on local
node if not already running
./”$steamdir/bin/”SWCC_ag_sT
ART_LOCAL.SH
Stop_server Check for Agent running on any
node and stop any instance of
the Agent
./”$steamdir/bin/”SWCC_ag_sT
OP_ALL.SH
Get_aconn_rs (none) (nothing)
Get_disk_vg_fs (none) (nothing)
Release_aconn_rs (none) (nothing)
Release_service_addr (none) (nothing)
