Installing and Configuring the HS-Series Agent 4–19
Check the index for the HACMP Enabler bits for your subsystem type. Install Enabler on
each node in the cluster using System Management Interface Tool (SMIT) or the installp
command line process. The enabler software provides HSG80 concurrency on HACMP
clusters of S70 and SP machines using the StorageWorks Fibre Channel Adapter,
DS-SWIA1-PC and DS-SWIA1-PD.
General Note on Software Installation
In the HACMP environment, install all Solution Software on each node in the cluster.
Follow the instructions in Chapter 3 and Chapter 4. Use the CD-ROM kit to install the
StorageWorks Software and Agent on all nodes.
To clarify, from the stgwks_aix.sh menu, any installation, upgrade, configuration or
removal of the StorageWorks Software including ODM files, Agent Software and Agent
configuration must be done on each node in the cluster. HACMP users have a slightly
different configuration menu that allows for local agent control.
Agent Maintenance Menu
HACMP Options
1) Change Agent Password 21) Check ALL nodes for running Agent
2) Change SNMP Enterprise OID 22) Stop running Agent on ALL nodes
3) (RESERVED 23) Check LOCAL node for running Agent
4) (RESERVED 24) Stop running Agent on LOCAL node
5) Uninstall Agent 25) Start Agent on LOCAL node
Client Options: Storage Subsystem Options:
6) Add a Client 10) Add a subsystem
7) Remove a Client 11) Remove a subsystem
8) Modify a Client 12) Modify a Subsystem
9) View Clients 13) View subsystems
10) Remove User from Mail Notification List
11) Modify Mail Notification List
